uPVC Plumbing Pipes : Allwin - Voda ( As Per ASTM D-1785 Standards )

We all need clean water and Allwin plumbing pipes used in potable water systems eliminates the risk of clean water being contaminated during transmission to the end user. The benefits for using Allwin plumbing pipes are numerous

Easy to install
Corrosion proof
Have smooth interior walls and can withstand long-term hydrostatic pressure.
Reduced installation and maintenance costs and increase the life span of the piping system

Applications

Building Construction
These pipes are useful for water connections to bathrooms, kitchen sinks, washbasins and laboratories.

Potable water supply
It can be used in commercial complexes, individual homes, flats, offices, hotels, hospitals and transports terminals.

Industrial Applications
Distribution of milk, chemicals and gases in dairies, plants and industrial estates. In agriculture, telecommunication, irrigation project etc

Benefits

Resistant to corrosion	Low frictional loss	Non toxic	Weather-resistant
Smooth internal surface	Tough and strong	Durable	Impact-resistant
Maintenance free	Termite-Proof	Good thermal and electrical insulation	Flexible
Light-weight	Self extinguishing	Moisture-proof	Wear and abrasion resistant
Easily be used with G.I. Fittings

Advantages over conventional G.I. Piping systems

Easy to handle
Durable. The solvent cement joints are leak proof and the joint is as strong as the parent material. The joints are tested under pressure as stipulated in the standard
Low transportation cost
Lower material & installation cost. uPVC pipe has a smooth surface, which reduce pressure losses and thus conserves electrical energy
High corrosion resistance
The lengths can be cut to required measurement and joined easily without laborious threading

Technical Specifications ( As Per ASTM D-1785 Standards Schedule 40 Specifications )

Nom Size (Inch) (mm)		Avg. OD (mm)	Min Wall Thick (mm)	Max. Work Pre. at 23^oC PSI	Max. Work Pre. at 23^oC (kg/cm²)
1/2"	15	21.34	2.77	600	42.19
3/4"	20	26.67	2.87	480	33.75
1"	25	33.40	3.38	450	31.64
1 1/4"	32	42.16	3.56	370	26.01
1 1/2"	40	48.26	3.68	330	23.20
2"	50	60.32	3.91	280	19.69
2 1/2"	65	73.02	5.16	300	21.09

Technical Specifications ( As Per ASTM D-1785 Standards Schedule 80 Specifications )

Nom Size (Inch) (mm)		Avg. OD (mm)	Min Wall Thick (mm)	Max. Work Pre. at 23^oC PSI	Max. Work Pre. at 23^oC (kg/cm²)
1/2"	15	21.34	3.73	850	59.76
3/4"	20	26.67	3.91	690	48.51
1"	25	33.40	4.55	630	44.29
1 1/4"	32	42.16	4.85	520	36.56
1 1/2"	40	48.26	5.08	470	33.04
2"	50	60.32	5.54	400	28.12
2 1/2"	65	73.02	7.01	420	29.53
